Name: Grass Parking Grids
Brand: IBRAN
SKU: IBRADRIVEX
Price: 3.0 GBP
Availability: InStock

Our heavy duty grass grids provide all the strength of traditional grass paving but with a much more natural appearance.

IBRAN-X's reinforced cellular structure and ridged, bumpy edge profile makes parking on grass practical, with all the durability and hardwearing strength of more conventional grass paving systems.

Locally made in our own factory in the Midlands, each grass paver grid is made to an exacting, dependable quality for trade and industry-assured standards. We're confident you'll love working with IBRAN-X Grass Parking Grids, just like the thousands of respected contractors we work with every year.

Each grid is 0.25m² (4 per sqm)
High load capacity of 500T/sqm
Rapid installation (360m² per hour)

Full specification at the bottom.

Grass Parking Grids Specifications


Dimensions:	500mm x 500mm x 40mm
Grid Coverage:	4 grids/m²
Ribbed Wall Thickness:	3.5mm
Colour:	Black (others available on request)
Cellular Space:	68mm x 68mm Squares
Weight:	860g/grid
Load Capacity:	500 tonnes per sqm
Axle Load Capacity:	30 tonnes
Material:	100% recycled PP/HDPE
Temperature Stability:	-50ºC to +90ºC
Recommended Fill:	Soil + Seed/Turf
Environmental:	None toxic, chemically inert & reusable
Slope Tolerance:	25% / 15º
Compliance:	SuDS & Part M Compliant
Nature:	Tree Safe

Easy to lay and good value for money.

Sort out my problem?

I've got a small high traffic area under trees that I'm hoping IBRAN grid can sort.

Exactly as described

Used for a summer house base and garden patio area and they're perfect.

Great Value Sturdy Grids

Great grids that click together well and support my Tesla on the lawn for home charging. They do require a flat surface but work well and very sturdy.

Five star!

Last year I made a huge car parking area in my front lawn to left of driveway, working a treat! Easy to clip together and insert into ground. Now I have just completed a walk way around the other side of lawn, very pleased so far. No maintenance. Grass just grows thrrough, yet provides a perfect area for parking and turning. Great delivery set up too. Highly recommend these grids.

1 2 3

IBRAN injection mould landscaping products in the UK

Made in Leicestershire.
IBRAN grass grids are proudly designed and made using machines and materials all sourced within 25 miles of our Leicestershire factory.

Grass parking grids transform your lawn into a green, all weather parking space

Made to last.
As well as a simple design that's easy to install, your next project needs dependable quality. We consciously choose quality material that's in budget, instead of the cheapest, to ensure that you have grass parking grids you can be confident in.

IBRAN-X Gravel Grids are easy to install and connect together quickly

Easy Installation

With interlocking clips pre-moulded into all four sides of the grids, you can create natural-looking parking areas in minutes.

First prepare your surface by digging out an area to a 40mm depth, assemble your grids within the hole and simply re-fill with any soil and seed combination that suits you. Alternatively, lay the grass grids directly onto free draining, compacted ground and fill.

For the very best results, you may want to consider a 50-80mm sub base of type 1 MOT. See below for more details.

Full Instructions

All Weather Parking

Want a discreet, natural looking parking surface? IBRAN-X grass pavers are virtually invisible when filled with grass.

IBRAN-X Grass Grids are designed to reinforce your grass parking space, helping you drive on and off in all weathers, with no wheel spin and no shredded turf.
